TSC TTP-244 Plus Service Manual

4
TTP-244 Plus Bar Code
Printer Service Manual
1.4 Basic Specifications
 Thermal transfer and direct thermal printing
 High dot density printing (203 dots/inch)
 Selectable print speeds at 2.0”, 3.0” or 4.0” per second
 Supports RS-232 and USB interface
 Maximum media width up to 4.49” (114 mm)
 Adjustable label edge guide
 International character sets
 Print area is 4.09”W x 40”L (without any file downloaded in the printer memory)
 User selectable bar code ratios and heights
 Prints on labels or tickets
 Equipped with black mark sensor
 Label stock and thermal transfer ribbon are easy to install
 Internal label print counter
 Self test and hex dump mode
 Downloadable fonts from label design software
Electronics/Communication Specifications
 Electrical
DC Motor: DC24V
Memory:
─DRAM: 8 Mb
─Flash: 2 Mb
Adapter 100~240VAC10%, 50~60Hz
Regulations: FCC Class A, CE Class A, C-Tick Class A, TÜ V/GS, CCC
 Communications Interface:
* RS-232/USB
* RS-232/Centronics (factory option)

TSC TTP-244 Plus Specifications

General

Resolution	203 dpi
Print Speed	4 ips
Print Method	Thermal Transfer / Direct Thermal
Weight	2.5 kg
Max. Print Width	4.25 inches
Max. Print Length	90 inches
Processor	32-bit RISC CPU
Interface	RS-232
Label Width	1 inch to 4.4 inches
Power Supply	100-240V AC, 50/60Hz
Operating Temperature	5°C to 40°C
Storage Temperature	-40°C to 60°C
Humidity	25% to 85% non-condensing
Label Thickness	0.06 ~ 0.19 mm (2.36 ~ 7.48 mil)
Dimensions	232 mm (W) x 156 mm (H) x 288 mm (D)
