5. Remove the teflon tube and stripper rod.
6. Remove the E ring, the right side and left side platen bushes.
7. Move the platen to the right of the mechanism.
8. Replace the platen and reassemble the removed parts in the reverse order of removal.
Teflon Tube
Platen bush (Left side)
E-ring
Platen
