TTP-244 Plus Bar Code

Printer Service Manual

4.10 Platen Replacement ............................................................................................... 31

5. TROUBLE SHOOTING ................................................................................................... 33

5.1 Trouble Shooting ...................................................................................................... 33

5.2 Calibrate the Gap Register ....................................................................................... 34

5.3 Self-test .................................................................................................................... 34

5.4 Ram Clear ................................................................................................................ 34

5.5 Diagnosis Operation Procedure ................................................................................ 34

5.6 Testing Sensors ....................................................................................................... 35

UPDATE HISTORY ............................................................................................................ 36

Other manuals for TSC TTP-244 Plus

Questions and Answers:

Need help?

Do you have a question about the TSC TTP-244 Plus and is the answer not in the manual?

General

Resolution	203 dpi
Print Speed	4 ips
Print Method	Thermal Transfer / Direct Thermal
Weight	2.5 kg
Max. Print Width	4.25 inches
Max. Print Length	90 inches
Processor	32-bit RISC CPU
Interface	RS-232
Label Width	1 inch to 4.4 inches
Power Supply	100-240V AC, 50/60Hz
Operating Temperature	5°C to 40°C
Storage Temperature	-40°C to 60°C
Humidity	25% to 85% non-condensing
Label Thickness	0.06 ~ 0.19 mm (2.36 ~ 7.48 mil)
Dimensions	232 mm (W) x 156 mm (H) x 288 mm (D)
