29
TTP-244 Plus Bar Code
Printer Service Manual
6. Replace with a new ribbon sensor PCB.
7. Reassemble the removed parts in the reverse order of removal.
Sensor Cover
Ribbon sensor PCB
Flat Tap Screw
