TTP-244M Pro/244ME Pro
TTP-342M Pro/342ME Pro
Bar Code Printer Service Manual
5. Insert cutter module tenons in the cuts on the carriage, slide the cutter
module to the right.
6. Fix the cutter module in place with the provided screw, plug in cutter
module power.
Cutter Mode
Front Panel
Cutter
Tenons
Cuts
