TSC TTP-345 Programming Manual

TSC AUTO ID Technology Co., Ltd. 197 Copyright 2013 All Rights Reserved.
 SET FEED_LEN
Description
This command can set the feeding length when FEED key is pressed. This setting will be memorized by
printer. The initialized value is the label length.
Syntax
SET FEED_LEN n
Parameter
Description
n
The feeding length in dot.
Note:
This command has been supported since V5.10 EZ and later firmware.
Example
Sample code
SET FEED_LEN 100
Result
The feeding length is 100 dots when you press the FEED button after this setting.

TSC TTP-345 Specifications

General

Print Method	Thermal Transfer
Resolution	300 dpi
Max Print Speed	5 ips
Max Print Length	90" (2286 mm)
Memory	8 MB Flash
Interface	USB 2.0, RS-232
Power Supply	External universal switching power supply
