TSC TTP-345 Programming Manual

TSC AUTO ID Technology Co., Ltd. 36 Copyright 2013 All Rights Reserved.
Syntax
BARCODE X,Y,"code type",height,human readable,rotation,narrow,wide,[alignment,]"content "
Parameter
Description
X
Specify the x-coordinate bar code on the label
Y
Specify the y-coordinate bar code on the label
code type
128
Code 128, switching code subset A, B, C automatically
128M
Code 128, switching code subset A, B, C manually
Control code
A
B
C
096
FNC3
FNC3
NONE
097
FNC2
FNC2
NONE
098
SHIFT
SHIFT
NONE
099
CODE C
CODE C
NONE
100
CODE B
FNC4
CODE B
101
FNC4
CODE A
CODE A
102
FNC1
FNC1
FNC1
103
Start (CODE A)
104
Start (CODE B)
105
Start (CODE C)
Use “!” as a starting character for the control code followed by three control codes. If the start subset
is not set, the default starting subset is B.
EAN128
Code 128, switching code subset A, B, C automatically
25
Interleaved 2 of 5
25C
Interleaved 2 of 5 with check digits
39
Code 39 full ASCII for TSPL2 printers
Code 39 standard for TSPL printers
Auto switch full ASCII and standard code 39 for PLUS models
39C
Code 39 full ASCII with check digit for TSPL2 printers
Code 39 standard with check digit for TSPL printers
Auto switch full ASCII and standard code 39 for PLUS models
39S
Code 39 standard for TSPL2 printers
93
Code 93
EAN13
EAN 13
EAN13+2
EAN 13 with 2 digits add-on
EAN13+5
EAN 13 with 5 digits add-on
EAN8
EAN 8
EAN8+2
EAN 8 with 2 digits add-on
EAN8+5
EAN 8 with 5 digits add-on
CODA
Codabar
POST
Postnet
UPCA
UPC-A
UPCA+2
UPC-A with 2 digits add-on
UPCA+5
UPC-A with 5 digits add-on
UPCE
UPC-E
UPCE+2
UPC-E with 2 digits add-on
UPCE+5
UPC-E with 5 digits add-on
CPOST
China post code
MSI
MSI code
MSIC
MSI with check digit
PLESSEY
PLESSEY code
ITF14
ITF 14 code
EAN14
EAN 14 code
11
Code 11

TSC TTP-345 Specifications

General

Print Method	Thermal Transfer
Resolution	300 dpi
Max Print Speed	5 ips
Max Print Length	90" (2286 mm)
Memory	8 MB Flash
Interface	USB 2.0, RS-232
Power Supply	External universal switching power supply
