For font "0", this parameter is used to specify the width (point) of true type
font. 1 point=1/72 inch.
y-multiplication
Vertical multiplication, up to 10x
Available factors: 1~10
For true type font, this parameter is used to specify the height (point) of
true type font. 1 point=1/72 inch.
For *.TTF font, x-multiplication and y-multiplication support floating value.
(V6.91 EZ)
space
Add or delete the space between lines in dot.
alignment
Text alignment. (V6.73 EZ)
0 : default (Left)
1 : Left
2 : Center
3 : Right
content
Data in block. The maximum data length is 4092 bytes.
Note:
 The internal font (font #1~#5) pitch between TSPL and TSPL2 is different.
 Font “0” and “ROMAN.TTF” internal True Type Fonts are available in TSPL2 language
printers, but not TSPL language printers.
 If there is any double quote (") within the text, please change it to \["].
 If font "0" is used, the font width and font height is stretchable by x-multiplication and
y-multiplication parameter. It is expressed by pt (point). 1 point=1/72inch.
 \[R] means carriage return character 0x0D.
 \[L] means line feed character 0x0A.
 This command has been supported since V6.91 EZ and later firmware.
 EPL2 and ZPL2 are for emulating Eltron
®
and Zebra
®
languages.
Example
Sample Code
SIZE 4,0.5
GAP 0,0
DIRECTION 1
CLS
BOX 10,10,800,100,2
BLOCK 15,15,790,90,"0",0,8,8,"We stand behind our products with one of the most comprehensive
support programs in the Auto-ID industry."
PRINT 1
CLS
BOX 10,10,800,100,2
BLOCK 15,15,790,90,"0",0,8,8,20,2,"We stand behind our products with one of the most
comprehensive support programs in the Auto-ID industry."
PRINT 1
Result
