GENERAL OPERATION
Turning the unit On or Off
Press and hold the RED Button on the top of the unit
to turn the unit ON.
Press and hold the RED Button again to turn the unit
OFF.
KEY Lock
Briefly press the RED Button on the top of the unit to
turn the Key Lock ON.
Briefly press the RED Button again to turn the Key
Lock OFF again.
Volume
Press the 5 key to increase the volume.
Press the 6 key to decrease the volume.
The volume level will be displayed from 00 to 31.
Squelch
Press the 5 key on the side of the radio to increase
the Squelch setting and the 6 key on to decrease
the Squelch setting. The Squelch level will be
displayed from 00 to 09. At maximum Squelch
setting, ‘AT’ is selected which represents an
automatic (preset) level setting.
Func Key
The Function key provides access to secondary
functions associated with the front panel keys. The
secondary function labels are printed below their
respective keys.
ENGLISH
16
TSC-3000R
