42 THE CONVECTION SYSTEM
NOTE: Door does not need to be removed to access
components inside the oven cavity - illustration is for
clarity purposes only.
Figure 35: Convection System Components - Oven Cavity
Figure 36: Convection System Components - Back Panel
2
1
5
4
4
6
NOTE: Oven door removed for illustration clarity;
not required for removing cavity components.
7
8
9
3
3
