12 VALVES NUMBERING
The valves in the drawing and the manual are numbered according to their
function. The following list includes all the valve numbers that are in use in
this manual
Size mm
2540 3870
1.
FEED WATER
13. Feed water – cool fast exhaust
14. Feed water – to reservoir
15. Feed water – to vacuum pump
3
2.4
4.5
3
4.5
4.5
2.
MINERAL
FREE
WATER
21. Mineral free water - inlet 3 4.5
4.
AIR
43. Filtered air - inlet 3 3
5.
VACUUM
52. Vacuum - to pump 4.5 4.5
7.
EXHAUST
73. Fast exhaust
74. Slow exhaust
4.5
3
4.5
3
9.
STEAM
93. Steam – to chamber
ASCO 1/4"
12VDC
ASCO 1/4"
12VDC
