8
3.4 Electrical Specifications
Value
Property
2540 3870
Heaters Power 3000W 6000W
Total Power 3200W 6200W
Voltage (V) 1 ph / 208 3 ph / 208
Amperage (A) 15 15
Frequency (Hz) 50/60 50/60
Protection against electrical shock Class I (IEC 60601-1)
Note: In order to avoid any injury by electrical hazard, it is
recommended that a ground fault protection device be installed in
the electrical panel feeding the autoclave (local codes may make
this mandatory).
3.5 Placing the Autoclave
Set the rear legs so that the chamber pitches down in the front at a rate
of 1/8” per foot. This ensures that water is completely drained out of
the chamber through the opening at the bottom front of the chamber.
To check, pour a glass of water into the bottom rear of the autoclave
and observe the water flow out of the chamber.
NOTE: Keep the back and the sides of the autoclave
approximately 1” (25 mm) away from the wall to allow ventilation.
It is recommended that enough space be left around the autoclave
to give a technician access for servicing the machine.
3.6 Connections to Utility Supplies
Using the ½” hoses and washers supplied with the unit
1. Connect the tap water inlet on the back of the autoclave to the feed-
water supply (city water supply).
2. Connect the mineral -free water inlet on the back of the autoclave
to a source of mineral-free water.
3. Connect the exhaust outlet on the back of the autoclave (using the
black hose supplied with the unit) to a suitable drain as described
above. Be sure to observe local codes for discharge of this type.
Note:
The drain hose from the exhaust outlet must be fixed very
securely to the drain, ensuring that when steam and water are
exhausted the hose is not allowed to recoil and cause injury to
personnel.
4. Connect the reservoir overflow on the back of the autoclave to a
suitable drain as described above.
5. Plug the power cord into the supply socket.
Attention! The pressure of the jacket does not decrease when the
equipment is turned off.
