97
Corrections
20.1 If the float will not move freely then
replace it
20.2 Unplug and replug the connectors to
insure a good connection. Fix and broken
wires.
20.3 If the float movement does not show a
change in the meter reading then replace
the float.
20.4.1 Unplug the FC37P cable connecting the
ANL-T2 and the DIG-T2. Inspect all
connectors for bent pins. Make sure the
flat cable’s connectors are in good
condition. Reconnect the cable.
20.4.2 Replace the ANL-T2 board
20.4.3 Replace the DIG-T2
Possible cause check-up and tests
20.1 Check if the float moves up and down
freely.
20.2 Check that the wires and connectors at
the float and the connector at JP11 and
JP12 on the ANL-T2 and the four pin DC
connector plugged into the back of the
electronic box are connected securely.
20.3 Disconnect the wires of the float switch
and check with an ohmmeter. Move the
switch up and down and observe that the
meter shows an open and closed circuit
20.4 If previous checks are OK the problem
could be on the ANL-T2 or DIG-T2
boards.
10. TROUBLESHOOTING (cont.)
10.4 In Process Malfunction (cont.)
Symptom
20. The float switch in the
water reservoir is always
ON or OFF.
To Next Page
