Instructions for use - Tiva2 - Tiva2H Thermodisinfector
5
5
1
1
2
2
3
3
3
3
8
6
7
1
1
8
6
7
TIVA2
TIVA2H
4
4
Fig. 2 - Main components of the thermodisinfector
1) Upper door with tempered glass (maximum capacity with open door 12 Kg).
- 2) Internal tank. - 3) Lower drawer door with lock. - 4) Upper door opening han-
dle. - 5) Detergent containers for washing and rinse aid/neutralising product. - 6)
Control panel. - 7) ON-OFF switch (machine on / off). - 8) Air suction lter.
