5.4 Filters, spray arms and regeneration rooms
5.4.1 Filters
Insertthesuppliedltersinthespecicpositions.Constantly
checkthecleanlinessofthelters,especiallythetankbottom
lter(3Fig.9).
Usethisltertohaveahighltering,takingintoaccountthat
it will have to be cleaned after each cycle performed to avoid
an excessive build-up of dirt.
Insertthemeshlter(2Fig.9)andplaceitinthetankseat.
Finally,insertthecentrallter(1Fig.9)inthemeshlterhole.
5.4.2 Spray arms
The two spray arms are supplied loose to avoid possible
breakage during transport. Place the two spray arms (top and
bottom) in their seats and tighten them to the relative central
pin inside the tank as shown in Fig. 10.
Fig. 9 - Filter unit
1) Central lter. - 2) Mesh lter. - 3) Tank bottom lter. - 4) Salt
tank cap.
1
2
3
4
