Installation
5.1 Built-in installation
The built-in machine can be inserted under a continuous work-
top or under the sink’s drip surface. The recess niche must have
aminimumspaceasshowningure7.
5.2 Electrical connection
HAZARD. Only qualied and experienced personnel can
connect the machine to the mains supply, in compliance
with the current laws and regulations.
WARNING: The main switch must be omnipolar circuit
breaker, with adequate differential protection, positioned
near the machine and not covered by machines or other
that may hinder its use.
The magnetic-snap safety system, or the fuses, must be cali-
brated according to the power indicated on the machine plate.
- Make sure that the measured voltage is equal to the one
reportedontheidenticationplateofthemachine;
- Check that the voltage does not differ by more than 10% from
its rated value;
- Make sure that the electrical system is equipped with an
efcientearthingconnection;
- Connect the cable installed on the machine to the three-phase
plug (not supplied) and insert it into the interlocked socket
next to the machine.
- The socket must be accessible after the machine installation.
Thisfacilitatesvericationoftheelectricalsafety,e.g.inrepair
or maintenance interventions.
The machine must be fed with current whose voltage, fre-
quency and protection values correspond to those indicated
on the data plate.
- The wiring diagram can be downloaded from
www.tuttnauer.com.
