Instructions for use - Tiva2 - Tiva2H Thermodisinfector
anything else necessary. These components should have all
the needed features and should be installed at the locations
shown on the installation scheme.
WARNING: The use of unsuitable parts, and/or the
implementation of installation procedures other than
those shown on the installation diagram, will immedi-
ately void the machine warranty.
The characteristics of the electricity network must be compat-
ible with the values required for correct operation indicated
onthemachineidenticationplateandonthetechnicaldata
sheet.
Themachinemustbeconnectedtoanefcientearthingsys-
tem (according to electrical safety standards).
The manufacturer is not to be held liable for any dam-
age caused by improper earthing of the machine or faulty
power supply.
Fig. 7 - Minimum distances in mm
TIVA2 = 650
TIVA2H = 820
50
2.5
2.5
⇒
