Chapter 13. Groups of parameters
Param.
No.
Name Unit
Access
level
Description
05.12 Power limit EG W 1 Power limit of the local loads for operation with
Energy Guard.
Minus sign means the possibility of sending energy to
the grid.
05.13 UDC Scale 1 A scale to calibrate the voltage measurement in the
charger DC circuit
05.14 Power limit EG rec. 2 Load power limit when operating with Energy Guard
module, at which the system will be supported by
energy from the battery
05.17 Low volt. charge 2 Critically low battery voltage. The battery voltage drop
to this level results in recharging it with energy from
the power grid (in the on-grid operation mode)
05.20 SPI 2 Charger parameter for monitor by the SPI adapter
05.21 Fault Reset 2 Charger fault reset
05.22 kp UDC 2 Setting of the proportional part of the DC voltage
controller
05.23 ti UDC 2 Setting of the integral part of the DC voltage controller
05.24 kp Ubat 2 Setting of the proportional part of the battery voltage
controller
05.25 ti Ubat 2 Setting of the integral part of the battery voltage
controller
05.26 kp I 2 Setting of the proportional part of the battery current
controller
05.27 ti I 2 Setting of the integral part of the battery current
controller
05.28 Force Charge 1 Forcing battery charging from the grid.
'Yes' will start charging the battery with the energy
from the grid.
05.29 BMS Type 1 Type of BMS used.
0 - no BMS system (lead battery)
1 - Nilar BMS
2 - Orion BMS
GROUP 10 – Service parameters
Param.
No.
Name Unit
Access
level
Description
10.01 SPI - 2 Parameter to view through the SPI adapter
10.02 U RMS gen. Ham V 2
Generator RMS voltage from which the "Resistors"
load is connected
10.03 Czest. Gen. ham Hz 1
Generator frequency from which the "Resistors" load
is attached
10.04 Min czas ham. s 1 Minimum time for connection the "Resistors" load
10.05 Hist. ham. Off % 1
Hysteresis defined in% in relation to the values given
in parameters 10.1 and 10.2, giving the load release
thresholds
10.06 Metrow / 10imp [ m/s 1
Wind speed corresponding to 10 pulses from the
anemometer
10.07 Ogon freq max Hz 2
The generator freq. above which the K2 relay is
activated
60 PS100 – User manual
