12
Connector (4) SATA connector
Controller Intel C602
Speed 3.0 Gb/s
SATA
From
(SCU)
RAID RAID 0/1/10 (Intel Matrix RAID)
USB
(7) USB2.0 ports (4 at rear, 2 at front, 1 type A
onboard)
COM
(1) DB-9 COM Connector (at rear, COM1) + (1)
Header (COM2)
VGA (1) D-Sub 15-pin VGA port
RJ-45 (2) GbE ports
Power
SSI 24-pin + 8-pin + 8-pin power connectors / (1) 4
PIN power connector for PCI-E
Front Panel (1) 2x12-pin SSI front panel header
PSMI (1) 1x5-pin header
IPMB (1) 1x4-pin header
Input /Output
SATA (4) SATA-II and (2) SATA-III connectors
Chipset Winbond W83795G
Voltage
Monitors voltage for CPU, memory, chipset & power
supply
Fan Total (7) 4-pin headers
System
Monitoring
Temperature
Monitors temperature for CPU & system
environment
Onboard Chipset Onboard Aspeed AST2300
AST2300 IPMI
Feature
IPMI 2.0 compliant baseboard management
controller (BMC) / Supports storage over IP and
remote platform-flash / USB 2.0 virtual hub / BIOS
update
Server
Management
AST2300 iKVM
Feature
24-bit high quality video compression / One 10/100
Mb/s MAC interfaces / 10/100 Mb/s MAC interface
Brand / ROM size AMI / 8MB
BIOS
Feature
Plug and Play (PnP) /PCI2.3 /WfM2.0 /SMBIOS2.3
/PXE boot / ACPI 2.0 power management /Power
on mode after power recovery / User-configurable
H/W monitoring / Auto-configurable of hard disk
types
Form Factor SSI EEB
Physical
Dimension
Board Dimension 12"x13" (305x330mm)
Operating System OS supported list Please refer to our OS supported list.
FCC (DoC) Class B
Regulation
CE (DoC) Yes
Operating Temp. 10° C ~ 35° C (50° F~ 95° F)
Non-operating
Temp.
- 40° C ~ 70° C (-40° F ~ 158° F)
Operating
Environment
In/Non-operating 90%, non-condensing at 35° C
