TYAN S7050 - Page 13

http://www.TYAN.com
13
Humidity
RoHS
RoHS 6/6
Compliant
Yes
Motherboard (1) S7050 Motherboard
Manual (1) User's manual / (1) Quick Ref. Guide
Installation CD (1) TYAN installation CD
I/O Shield (1) I/O Shield
Package Contains
Cable SATA (6) SATA signal cables
TYAN S7050 (S7050WGM2NR[BTO])
Supported CPU
Series
Intel Xeon Processor E5-2600 Series
Socket Type / Q'ty LGA2011 / (2)
Thermal Design
Power (TDP)
wattage
150W
Processor
System Bus
Up to 8.0/ 7.2/ 6.4 GT/s with Intel QuickPath
Interconnect (QPI) support
PCH Intel C602 with upgrade ROM module
Chipset
PCI-E Switch Pericom PI3PCIE3412
Supported DIMM
Qty
(8)+(8) DIMM slots
DIMM Type / Speed
DDR3/DDR3L 800 / 1066 / 1333 / 1600 RDIMM,
800 / 1066 / 1333 UDIMM / LRDIMM / Support
DDR3 Unbuffered and Register ECC
Capacity up to 128GB UDIMM
Memory channel 4 Channels per CPU
Memory
Memory voltage 1.5V or 1.35V
PCI-E
(1) PCI-E x4 slot ( x4 link,) / (1) PCI-E x16 slot
( x16 link or x8 link,) / (1) PCI-E x8 slot ( x8 link or
x0 link,) / (1) PCI-E x16 slot ( x16 link or x8 link, ) /
(1) PCI-E x8 slot ( x8 link or x0 link,)
Expansion Slots
PCI (1) PCI 32-bit slot
Recommended
Barebone /
Chassis
Mechanical
Compliant
KFT48 / KGN70M1 / KGTN70M1
Port Q'ty (2) GbE ports
LAN
Controller Intel 82574L
Connector (8) SAS connector
Controller Intel C602 with TRK-5 upgrade ROM module
Speed 3.0 Gb/s
Storage
SAS
RAID RAID 0/1/10
