6-13
6)The oil seal should be coated with grease in
advance.Then install them carefully,assuring
that their lips are not turned over.
7) The reassembled final case (B) should turn
smoothly until it makes contact the stopper.
8) When the wheel(tire) is reinstalled,turn it by
hand to make sure that all the mechanism
turns smoothly without making any noise.
9) After adjustment of the toe-in,perform road
tests.There should be no abnormalities such
as vibration,abnormal noises,defected
steering wheel operation,etc.
9-11Kgf.m
(65-80 ft.lbs)
Wheel clamping torque
