8. FILTER

DONAX TD or RPM THF 500Applicable oil

-30 ∼130℃

6231 ㎠

35 ㎛

3510

11000㎠Filtration area

Working oil temperature (℃)

25 ㎛Filtration density

57Rated flow rate(ℓ/min.)

4110/T390(T400)/T430(T450)/T431(T451)Model

2) Line filter

150 meshFiltration density (mesh)

790 ㎠Filtration area

35Rated flow((ℓ/min.)

9-34

8.3 REPLACEMENT

Check the O-rings for damage or deformation

and replace defective ones.When installing the

filters,be sure to install the O-rings properly

with grease applied.

1.Filter

2.O-ring

3.Bolt

4.Filter

5.Spring

6.Plug (PT1/10)

8.1 GENERAL DESCRIPTION

The tractor is equipped with two oil filters:

suction filter(1) and line filter(4),for better

filtration.

8.2 SPECIFICATIONS

1)Suction filter

Fig. 9-67 Filter
