CBF 125 AIR COOLING ENGINE SERVICE MANUAL
RENEGADE SPORT & SCRAMBLER X 125 EFI
106
MalfcodeP0118
InformationCoolant/Oil Temperature Sensor Circuit High Voltage or Open
STEP
OPERATION
SOLVED
FOLLOWING STEP
1
Connect the diagnostic tool, and ignition on.
next
2
check whether the data ofengine temperature equals to
the real temperature.
Yes
Step 5
No
Next
3
Remove the connector and use the multimeter to check
whether the resistance between pin A and C of the sensor is
reasonable according to the temperature.
Yes
Step 5
No
Next
4
Use the multimeter to measure whether the voltage
between A and C is about 5V.
Yes
Next
No
Check the harness
5
check whether the following pins are short to battery or
open: J2-10, J2-14 of the ECU and pin C and D of the sensor.
Yes
Harness issue
No
Next
6
crank the engine and stay idle. Check whether the ‘engine
temperture goes high when engine get warm.
Yes
Help
No
Change the sensor
MalfcodeP0122
InformationTPS Circuit Low Voltage or Open
STEP
OPERATION
SOLVED
FOLLOWING STEP
1
Connect the diagnostic tool, and ignition on.
next
2
Check whether the data ofThrottle openingis bettwen
0%-1%.
Yes
Step 5
No
Next
3
Open the throttle to 100% slowly, check whether the data
of throttle opening’ goes to between 90%-100%.
Yes
Step 5
No
Next
4
Repeat Step 3, chek whether the data jumps when open
the throttle slowly.
Yes
Change the sensor
No
Next
5
Remove the connector and check whether the following
pins are short to gound or open: J2-12, J2-16 of ECU and pin
A and C of the sensor.
Yes
Harness issue
No
Next
6
Use multimeter to check whether the voltage between pin
A and B is about 5V.
Yes
Help
No
Step 5
