CBF 125 AIR COOLING ENGINE SERVICE MANUAL
RENEGADE SPORT & SCRAMBLER X 125 EFI
60
6.5 Clutch (extraction and installation)
6.6.1. Clutch extraction.
• Dismantle 4 bolts from end cover of
clutch, then take out end cover of
clutch, bearing, declutch spring.
• Dismantle locknut and washer of
clutch
• Take out upper and lower pressure
plate of clutch, drive and driven friction
plates
• Take out declutch gasket and outer case
of clutch
