CBF 125 AIR COOLING ENGINE SERVICE MANUAL
RENEGADE SPORT & SCRAMBLER X 125 EFI
59
• Rotate control arm, so that spring falls
into position as shown in figure. Then
install pushing rod of clutch
.
• Assembly location pins and new paper
gasket.
• Removal clutch gasket and engine oil
from crankcase before assembling
• Assemble right cover, bracket, bolts.
(First, tighten the bolt at locating pin, then
tighten other bolts alternatively)
Tightening Torque: 10 N.m
Dismantle the oil filter and gears of oil pump.
