CBF 125 AIR COOLING ENGINE SERVICE MANUAL
RENEGADE SPORT & SCRAMBLER X 125 EFI
58
• Take out clutch control arm and oil seal
• Check clutch control arm for deformation,
check iif pushing rod and spring are
damaged if they are, replace them with
new ones
• Partial assembly of right cover
• Replace oil seal of control arm with new
one. Apply appropriate amount of
lube oil onto lever of control arm,
then install the arm into right cover.
• Use tools to knock cotter pin into
corresponding hole of control arm
.
To Next Page
