8.2. Technical specifications
unit: mm
Item
Standard
Service Limit
Crankshaft,
Connecting
Rods
Connecting Rod
Large End:
Radial Clearance
0~0.008
0.03
Side Clearance
0.1~0.35
0.5
Crankshaft Runout
0.03
0.08
Fork
Fork Outer diameter
Φ9.966~φ9.984
Φ9.93
Fork Inner diameter
Φ10.000~φ10.018
φ10.05
Shift Fork Ear Thickness
4.93~5.00
4.5
Drive train
Gear tooth inner
hole diameter
M4
Φ20.000~φ20.021
Φ20.04
M5
Φ20.000~φ20.021
Φ20.04
C1
Φ20.500~φ20.521
Φ20.55
C2
Φ23.000~φ23.021
Φ23.04
C3
Φ23.025~φ23.046
Φ23.06
Bushing diameter
M4
Φ19.959~φ19.980
Φ19.93
M5
Φ19.959~φ19.980
Φ19.93
C1
Φ20.459~φ20.480
Φ20.41
C2
Φ22.984~φ23.005
Φ22.95
Bushing inside
diameter
M4
Φ17.000~φ17.018
φ17.04
C1
Φ17.000~φ17.018
φ17.04
C2
Φ20.000~φ20.021
Φ20.04
The shaft diameter
M4
φ16.966~φ16.984
φ16.93
C1
φ16.966~φ16.984
φ16.93
C2
φ19.974~φ19.987
φ19.94
C3
φ19.979~φ20.000
φ19.95
