CBF 125 AIR COOLING ENGINE SERVICE MANUAL
RENEGADE SPORT & SCRAMBLER X 125 EFI
86
8.3.6. Dismantle fastening bolt on right
crankshaft
8.3.7. Dismantle fastening bolts on crankshaft
8.3.8. Place crankcase properly with right half
downwards. Knock counter shaft and
crankshaft with rubber hammer to loosen
adhesive on halves (left and right). Place
horizontally the crankcase and remove left
half upwards
8.3.9. Dismantle location pins
