CBF 125 AIR COOLING ENGINE SERVICE MANUAL
RENEGADE SPORT & SCRAMBLER X 125 EFI
57
6.5. Right cover -extraction and installation-
• First drain off oil from engine, remove bolts
from right cover.
• Remove the paper gasket and positioning
pin
• Check the crankshaft oil seal is intact
• Removal of right cover
• Take pushing rod of clutch
• Use tools to dismantle cotter pin on
control arm and take out the spring
