CBF 150 AIR COOLING ENGINE SERVICE MANUAL
RENEGADE SPORT & SCRAMBLER X 125 EFI
8
2.1 Engine Maintenance Cycle
Cycle
Maintenance
Travel
Inspection
Travel Kms （ ×1000 Km ）
1
3
6
9
12
Spark Plug
I
I
R
I
Valve Clearance
I
I
I
I
I
Engine Oil
I
R
R
R
R
R
Fuel Filter
R
R
R
R
R
Oil Strainer
C
C
Oil Filter
R
R
R
R
R
Idle Speed
I
I
I
I
I
I: Inspect, clean, adjust, lubricate or replace if necessary. C: Clean R: Replace
IMPORTANT NOTE: to guaranty the perfect function of fuel injection system, the fuel filter must
be changed every 3000 Km, as is specified in the table; and the fuel pump filter changed every
10000 km.
2.2 Engine Maintenance Standards
Item
Standard
Service Limit
Engine oil
Specification
SJ 10W/40
1.2L
Capacity
Filter is not removed
1
Oil filter removed
1.1L
Dry Engine
1.2
Valve Clearance
Inlet
（ 0.04-0.06 ） mm
0.10mm
Exhaust
（ 0.04-0.06 ） mm
0.15mm
Spark Plug
Standard
CPR8EA-9(NGK)
High RPM extreme use
CPR9EA-9(NGK)
Electrode clearance
(0.8-1.0) mm
Engine Idle Speed
1400±100rpm
2.3. Torque Standards
Spark Plug ： 16 N.m.
Oil Discharge Bolt：24 N.m.
Engine Oil Cap Bolt：10 N.m.
Head Cap (cylinder head) Bolts：10 N.m.
Valve Clearance Nuts：14 N.m.
