um CBF 125 - Magneto Rotor Disassembly; Starting Motor System Check

CBF 125 AIR COOLING ENGINE SERVICE MANUAL
RENEGADE SPORT & SCRAMBLER X 125 EFI
78
7.3.12. Starting motor system check.
Assemble large starting gear onto magneto
rotor, then check if the gear can rotate
normally, making it rotate
counterclockwise
7.3.13. Magneto rotor disassembly.
7.3.13.1. Use special tools to fix rotor, then
dismantle rotor bolts.
7.3.13.2. Take out overrunning clutch
7.3.13.3. Check holder and wedge block for
damage.
