CBF 150 AIR COOLING ENGINE SERVICE MANUAL
RENEGADE SPORT & SCRAMBLER X 125 EFI
6
1.7 Clutch unit ： mm
Item
Standard
Service Limit
Clutch
Clutch Spring Free Length
41.1-41.9
40
Friction Plates Thickness
2.92-3.08
2.6
flatness of clutch driven plate
0.20
Driven gear inner hole diameter
Φ23.000 ～φ23.021
φ23.08
Shaft sleeve
Collar diameter
Φ22.960～φ22.975
Φ22.93
Bushing aperture
Φ16.990～φ17.008
φ17.04
The spindle diameter
Φ16.966～φ16.984
Φ16.95
1.8 Driver Train unit ： mm
Item
Standard
Service Limit
Crankshaft,
Connecting Rods
Connecting Rod
Big End:
Radial Clearance
0～0.008
0.03
Side Clearance
0.1～0.35
0.5
Crankshaft Run out
0.03
0.08
Fork
Outer diameter of fork shaft
Φ9.966～φ9.984
Φ9.93
Inner diameter of fork
Φ10.000～φ10.018
φ10.05
Shift Fork Thickness
4.93～5.00
4.5
Transmission
Gears inner hole
diameter
M4
Φ20.000～φ20.021
Φ20.04
M5
Φ20.000～φ20.021
Φ20.04
C1
Φ20.500～φ20.521
Φ20.55
C2
Φ23.000～φ23.021
Φ23.04
C3
Φ23.025～φ23.046
Φ23.06
Bushing external
diameter
M4
Φ19.959～φ19.980
Φ19.93
M5
Φ19.959～φ19.980
Φ19.93
C1
Φ20.459～φ20.480
Φ20.41
C2
Φ22.984～φ23.005
Φ22.95
Bushing internal
diameter
M4
Φ17.000～φ17.018
φ17.04
C1
Φ17.000～φ17.018
φ17.04
C2
Φ20.000～φ20.021
Φ20.04
Shaft diameter
M4
φ16.966～φ16.984
φ16.93
C1
φ16.966～φ16.984
φ16.93
C2
φ19.974～φ19.987
φ19.94
C3
φ19.979～φ20.000
φ19.95
