CBF 125 AIR COOLING ENGINE SERVICE MANUAL
RENEGADE SPORT & SCRAMBLER X 125 EFI
26
4.2.5 Detecting oil passage and clean it using air gun
4.2.6 Assemble bolts and washers after the head cover
is checked (Need to be replaced old washer by a new
one)
4.2.7 Assembly location pin and a new O-ring
4.2.8 Clean the sealing ring groove and mount a new
cover sealing gasket, after that, assemble to the
cylinder head together.
To Next Page
