CBF 125 AIR COOLING ENGINE SERVICE MANUAL
RENEGADE SPORT & SCRAMBLER X 125 EFI
68
6.6.2.4. Align keyway on drive gear with
woodruff key on crankshaft and
assemble them. Apply appropriate
amount of engine oil on gears.
6.6.2.5. Assemble oil filter, washer, locknut
6.6.2.6. Tighten nut to specified torque;
Tightening torque: 64N.m
6.6.2.7.
Assembly the filter cover and paper
gasket, finally tighten bolt
Tightening torque: 4N.m
