mode shall be used for v ideo signals. Waveform ca
n
not be displayed stably until setting correct trigger
mode
.
Please strive to set coupling to high-frequenc
y
inhibition and low-frequency inhibition display to
filter high low frequency noise triggered b
y
interference
5. To press RUN/STOP key without any dis play
:
To check if trigger mode of trigger menu is i
n
normal or single gear or not. It has to check if trigger
level is out of waveform scope or not
.
Trigger level shall be in the middle or trigger mode
shall be set to AUTO gear if yes
.
To press AUTO key for automatic setup as
above
.
6. Display speed will reduce after opening average
time sampling mode
.
In general speed will reduce normally if
average times exceed
To reduce average times.
7. Staircase waveform displa
y
A
s normal phenomenon, horizontal time base
can increase under super-low horizontal time base
gear so as to increase horizontal r esolution and
improve display
.
Possible display type is vector and sampli n
g
points can be connected for staircase waveform
display. Display type can be set to point displa
y
Ĺ


ķ
ĸ
ķ

ĸ
ķ
ĸ

3
