Oper ating Man ual fo r UTD 2000/3000
UTD2000/3000 series digital storage oscillograp
provides simple front panel with clear functions to
users for all basic operations. Scal e and position of
various channels can provide intuitional operatio
to meet usage habits of traditional instruments
Users can use it skillfully without learning and
being familiar with operation for a long time. Users
can also press AUTO key directly to acceler ate
adjustment and facilitate measurement
ppropriate waveform and gear setup can be
shown on the instrument panel
UTD2000/3000 series digital storage oscillograp
also has high-performance indicators and powerful
functions to fulfill measurement tasks quickl
besides easy usage. Quicker signals can be
observed by UTD2000/3000 series digital storage
oscillograph by real-time sampling of 500MS/s (or
1GS/s) and equivalent sampling of 25GS/s (or
50GS/s). It c an capture and analyze waveform
easily by powerful trigger and analysis capacity
Users can also observe and analyze signal
problems quickly and clearly by clear LCD displa
and mathematical calculation function. We can see
that such series of digital storage oscillograph ca
meet your measurement requirements by following
performance characteristics
High-resolution colorful LCD display system w it
resolution of 320 240 or 800 480
To support plug and play USB storage instrument
to communicate with computer
utomatic waveform and status setup
Waveform, setup, bitmap storage, waveform and
setup reoccurrence
Ɣ
Ɣ
Ɣ
Ɣ
Ɣ
