Uniden UBC 245XLT Trunk Tracker II - Front View

1. DC Power Jack 10. Light
2. Scan Key 11. Speaker
3. Manual Key 12. Display
4. Trunking Key 13. Remote jack
5. Decimal Key /ATT 14. Keypad
6. Service Key 15. Enter Key /Remote
7. Limit Key/Down Key 16. Search Key
17. Hold Key/Up Key
8. Priority Key/Turbo Key
18. Lockout Key
9. Delay Key 19. Data Key
/ Lock Key
Front View
ii
.
BATT
1 2 3 4 5 6 7 8 9 10
BANK
TRUNK
AT T
2
3
4
5
6
7
8
9
10
11
12
1
14
13
15
16
17
18
19
DATA POLICE RR AIR MRN UHFCB
SCAN
SEARCH
PRI HOLD DLY L/O
