Unilumin UMini W User Manual

22
2.4.2 Signal Cable Connection
Signal cables shall be connected based on the wiring diagram of the delivered products for the project.
Fig 2-26 Signal Cable Connection Diagram of UMini W1.2
2.4.3 Power Cable Connection
Power cables shall be connected based on the wiring diagram of the delivered products for the project.
Fig 2-27 Power Cable Connection Diagram of UMini W1.2
Sending Box
AC Power Cable
