6.2.2 Replacement of Power Supply

Cut off the power supply of the display , replace a power supply of the LED display based on the following steps:

Front maintenance step Picture Description

Step 1

Find the faulty cabinet

and disconnect the power

supply

Step 2

Remove module and

HUB card

Step 3

Remove the DC output

port and power supply

fixing screw, gently

remove the power supply

to the right and replace

the new power supply

Step 4

Remove the power supply

and replace it

6.2.3 Replacement of Receiving Card

Cut off the power supply of the display , replace receiving card of the LED display based on the following steps:
