Fig 2-7 Back view of front maintenance Installation
Fig 2-8 Front View of Cabinet Installation
Fig 2-9 Front View of the Display
2.2.2 Installation of Fixed LED Display-Rear Installation(Optional)
1) Check whether the bottom beam is level. Make sure that its levelness is within ±1mm. (bottom
beam is a must have)
2) Install the cabinets sequentially from bottom to top and from middle to both sides. In addition,
Front Mounting plate
Bolts
Square tube
To Next Page
