9.ERROR CODE
105
Sequence Error 5
This error occurs when you try to start measuring sequence while Set point 1
signal is still ON “1”. (Note that you can select a setting to ignore weight when
the sequence starts.)
First, check the relation between the set values for SP1 and Final, and then check
the following:
・ Sequence started prematurely while material still remains in the metering tank
・ Start turned ON prematurely
・ Material can not be discharged properly, due to valve blockage, etc.
Change stop signal from OFF to ON to remove the sequence error.
For detailed description of the course of sequence control, see
Section 6-2. "Simple Comparison Control and Sequence Control" ,
page67.
