5.DISPLAY SETTINGS
58
Digital tare subtraction (expansion)
Using this function, the user can inhibit two tare subtraction related actions while
tare subtraction is enabled: modification of tare set value and ON/OFF toggling
of Digital tare subtraction.
Select “1” in the relevant bit in the following register to inhibit these two actions
while tare subtraction is enabled.
5-13. Sign Reversal during Discharge Control
When measuring weight of raw material tank from which a fixed quantity of
material is drawn (Discharge weighing), Net weight will increase in negative
direction. Using this sign reversing function, the user can obtain Net weight as a
positive value.
To reverse the sign of Net weight output, select “1” in the relevant bit in the
following register.
10
0
10
0
10
0
10
0
Undefined
m+31
Digital tare subtraction (expansion)
Range of tare subtraction
Tare value read
1：inhibit
0：don’t care
1：0 < Tare < Capacity
0：Unrestricted
1：Only while reading is stable
0：Always
10
0
10
0
10
0
10
0
Sign convention for discharge control
m+28
1：Sign of Net weight not reversed
0：Sign of Net weight reversed
Complete signal output mode
Upper/Lower limit comparison mode
Over/Under comparison mode
To Next Page
