6.WEIGHING MODE SETTING AND OPERATION
79
* If the control does not use SP1 and SP2 signal, the values for these two
parameters must be set equal to that of Final.
6-5. Near Zero / Upper Limit / Lower Limit
These parameter settings are used as reference for fixed value final discharge
control.
〈Conditional equation〉
Near zero: “1” when Weight <= Near zero set value (inpur range: 0-99999)
Upper limit: “1” when Weight > Upper Limt set value (input range: 0-99999)
Lower limit: “1” when Weight < Lower limit set value (input range: 0-99999)
