6.WEIGHING MODE SETTING AND OPERATION
78
6-4. Final / Set Point 2 / Set Point 1 / FF CPS. / Over / Under
These parameters are used as target and reference values for Final discharge
control.
0
Near zero
Final – SP1
Final – SP2
Final - FF CPS.
Final
Weight
Over
Under
Time
Near zero
SP1
SP2
SP3
OFF
ON
ON
ON
ON
OFF
Over
Go
ON
Under
Parameter settings for Final discharge control
Parameter Criteria equation
Near zero Weight <= Near zero
SP1 Weight >= Final – SP1
SP2 Weight >= Final – SP2
SP3 Weight >= Final – FF CPS.
Under Weight < Final - Under
Over Weight > Final + Over
Go Final + Over >= Weight >= Final - Under
