6.WEIGHING MODE SETTING AND OPERATION
69
6-2-2. Sequence Control
Sequence control starts comparing the measured value (weight) with the weigh-
ing parameters when the system receives a start signal. SP1, SP2, and SP3
outputs are all initialized to "1", and one of these outputs subsequently changes
to "0" depending on the result of control calculation.
Sequence control can be classified into following categories:
1）Normal sequence control
Control operation (weighing) starts when the system receives a start signal,
and is terminated when the system sends off "Complete" signal.
2）Sequence control with Auto jog
This control mode is accompanied by Auto jog after the weighing procedures
completed.
To Next Page
