6.WEIGHING MODE SETTING AND OPERATION

・Triggering schedule of Over/Under comparison is determined by parameter

settings for the Over/Under comparison mode (Weighing function 2

parameters for m+28CH). The figure illustrates operation with “Regularly”

selected.

・“Complete" is output according to the conditions specified for the complete

signal output mode (Weighing function 2 parameters for m+28CH).

・ t1: Comparison inhibit time m+20CH

t2: Compare time m+21CH

t3: Complete output time m+22CH

・ Conditional expressions:

　・ Near zero outputs "1" when Weight value <= Near zero set value

　・ SP1 outputs "1" when Weight value >= Final - SP1

　・ SP2 outputs "1" when Weight value >= Final - SP2

　・ SP3 outputs "1" when Weight value >= Final - FF. CPS

　・ Under outputs "1" when Weight value < Final -Under

　・ Over outputs "1" when Weight value > Final+Over

　・ Go outputs "1" when Final+Over >= Weight value >= Final - Under

・ Near zero comparison uses either signed values (Gross weight / Net weight) or

absolute values (|Gross weight| / |Net weight|) depending on the Weighing

function 1 settings for m+27CH.

・ Data used for SP1/SP2/SP3 outputs and Over/Go/Under comparison can be

either Gross or Net weight depending on Weighing function 1 settings for

m+27CH.
