Unipulse F159 User Manual

2.CONNECTION
7
CAUTION
・ F159 supplies 10V excitation voltage. Use a load cell with rated excitation voltage of 10V
or higher, otherwise abnormal heating and damage to the cell may result.
・If you use F159 using 4-wire connection configuration, never fail to connect between
+EXC and +S, and –EXC and –S. Although the system may function apparently well
without these jumpers, over-voltage excitation can occur any time resulting in anomalous
heating and damage to the load cell.
