3.DATA EXCHANGE WITH CPU
23
CZ
CZ (Center Zero) bit helps the user find out the center of scale interval. The
Minimum scale division is divided into four sub-divisions, and CZ bit becomes
“1” if reading falls within the central two sub-divisions.
ZT in progress
ZT in Progress bit becomes “1” when Zero tracking is enabled.
* For more information, see Section 5-5. "Zero Tracking (ZT)" , page54.
HOLD in progress
HOLD in Progress bit becomes “1” while Weight value is frozen.
Tare subtraction in progress
This bit becomes “1” while tare subtraction function is enables (Tare must have
non zero value).
nn+1
CZ bit “1” CZ bit “1”
1/4 of Minimum scale division
Minimum scale division
When 1/4 scale division is disabled, CZ becomes “1” only if
reading coincides with true zero point.
-1 01
CZ bit “1”
1/4 scale division
