4.CALIBRATION
41
Minimum scale division
Defines the Minimum scale division or scale interval (Input range: 1 – 100)
Gravitational acceleration
This factor compensates regional difference in Gravitational acceleration. This
factor needs not be specified if the system is used in the same area where actual
load calibration took place.
Two methods are provided to enter correct Gravitational acceleration: One
method uses area numbers and the other requires direct input of Gravitational
acceleration value.
In the former method, the user enters a area number (01-16) from the GA
correction table for the region where actual load calibration will take place, and
then select a area number corresponding to the region where the system is
installed. Correct Gravitational acceleration compensation will be performed
using these two area numbers.
The latter method, direct input of Gravitational acceleration, is selected by
specifying area number “00”.
Input range:
Area number: 00-16
Gravitational acceleration: 9.700-9.999
Gravitational acceleration
10
2
10
1
10
0
Minimum scale division
m+43
01 9.806 02 9.805 03 9.804 04 9.803
05 9.802 06 9.801 07 9.800 08 9.799
09 9.798 10 9.797 11 9.796 12 9.795
13 9.794 14 9.793 15 9.792 16 9.791
10
1
10
0
Area number
10
0
10
-1
10
-2
10
-3
Gravitational acceleration
m+50
m+51
To Next Page
