2.1.2 Outdoor Unit Data – Models CU150, CU200, CU250
Model CU150 CU200 CU250
Casing color RAL 7032 RAL 7032 RAL 7032
Dimensions (LxDxH) mm 900x380x585 900x380x585 900x380x585
m
3
/h 2465 3230 3400
Air flow (at high speed)
cfm 1450 1900 2000
Noise Level (see note 1) dbA 44 46 46
Fittings Type Flare Flare Flare
Expansion Device Capillary Tube Capillary Tube Capillary Tube
Axial Fan Diameter/No. mm 500/1 500/1 500/1
Outdoor Fan Motor KW 0.15 0.15 0.15
Motor Capacitor µF/Volt 5/400 5/400 5/400
Speed (High/Low) R.P.M 900/700 900/700 900/700
Face Area m²/ ft² 0.34/4.1 0.34/4.1 0.34/4.1
Tube Diameter Inch 3/8" 3/8" 3/8"
Rows Deep 2 3 3
Coil
Fins Spacing Per Inch 12 12 12
Net Weight Kg. 53 71 73
Notes:
1. Noise level measured at a 4 m. distance in free field.
